WEIGHING AND PACKING LINES (UP TO 400 BAGS PER HOUR)


PARAMETERS:

  • Output:
    • Up to 180 bags / hour (gross weigher)
    • Up to 400 bags / hour (net weigher)
Depending on the possibilities and manual skills of the operator.
  • Weighing range: 5 – 50 kg
  • Bags: paper, plastic, wpp
  • For products: animal feed, seeds, soy and rapreseed, wooden pellet, granulates, etc.
  • Automation level: semi-automatic
Category Custom Catalog: FOR OPEN MOUTH BAGS | WEIGHING AND PACKING SYSTEMS
PURPOSE: WEIGHING AND PACKING
OUTPUT: OUTPUT UP TO 500 BAGS PER HOUR
AUTOMATION LEVEL: SEMI-AUTOMATIC

EQUIPMENT:

  • Buffer tank with structure
  • Electronic gross / net weigher
    • With a belt feeder, screw feeder or gravity feed
  • HMI in language adapter to the customer’s needs
  • Pneumatic spout (adapted to the size of the bag)
  • Automatic ALIMA sewing system with 2 or 1-thread head from FISCHBEIN | YAO HAN | NEW LONG | UNION SPECIAL
  • Belt conveyor
  • Bag turning system
  • Inclined conveyor
  • Conveyor with delivery rollers



OPTIONAL EQUIPMENT:

  • Tank with support structure and level sensors
  • Automatic infeed introducing the upper part of the bag to the sewing head
  • Modular conveyor
  • Metal detector
  • Other elements as requested by the Investor



BENEFITS:

  • Lower production costs
  • Fast return on investment
  • Increased production efficiency
  • Better ergonomics of the workplace
  • Possibility of legalization of the weigher
  • The ability to adjust the performance of the device to the customer’s needs
  • Possibility of enriching the device with other elements
